Need five lighting controls grouped on one standard-size wall plate? This 5 gang vertical light switch combines five individual switches in one white vertical plate for larger kitchens, open-plan areas, offices, hospitality spaces and other installations with several lighting zones.
The product is rated at 220–240V, 10A, supports 2-way switching as described in the existing product information, includes a loop terminal and has a removable clip-on front surround.
It is listed as SAA certified to AS/NZS 3133:2013 + A1 and carries a 10-year warranty when installed by a licensed electrician.
Quick Guide: Is This 5 Gang Light Switch Right for You?
| Switch type | 5-gang vertical wall switch |
| Controls | Five separate lighting circuits |
| Rating | 220–240V, 10A |
| Orientation | Vertical |
| Size | W75 × H118 × D30mm |
Why Choose This 5 Gang Vertical Light Switch?
- Five switches on one compact plate for five separate lighting circuits.
- 2-way switching capability as listed in the current product information.
- Loop terminal included for installation flexibility.
- Clip-on removable surround for a neat finished appearance.
- Polycarbonate construction in a vertical format.
- SAA certified and listed to AS/NZS 3133:2013 + A1.
- 10-year warranty when installed by a licensed electrician.
What Does 5 Gang Mean?
A 5 gang light switch has five switch mechanisms on one wall plate. It is useful where five separately controlled lighting circuits meet at the same position. Gang count refers to the number of switches; it is different from 2-way switching, which describes a multi-location circuit arrangement.
Where Can a 5 Gang Light Switch Be Useful?
Five-gang plates are most useful in larger or more complex spaces with several lighting zones—for example open-plan living areas, larger kitchens, offices, hospitality spaces or rooms with general, feature and task lighting controlled separately.
5 Gang Light Switch Specifications
| Specification | Details |
|---|---|
| Model / SKU | 3014385252038 |
| Voltage | 220–240V |
| Maximum current | 10A |
| Number of gangs | 5 |
| Dimmable | No – standard on/off switches |
| Removable cover | Yes |
| Size | W75 × H118 × D30mm |
| Material | Polycarbonate |
| Orientation | Vertical |
| Standard | AS/NZS 3133:2013 + A1 |
| Certification | SAA |
| Warranty | 10 years when installed by a licensed electrician |
Compare 1 to 6 Gang Light Switches
Need a different number of controls? Compare the 1 gang, 2 gang, 3 gang, 4 gang and 6 gang vertical light switches.
Power Points, Dimmers and NZ Compliance
For the same project, compare the double vertical power point, double horizontal power point and LED dimmer switch.
The current product documentation lists SAA certification and AS/NZS 3133:2013 + A1.
Fixed electrical wiring should be completed in accordance with New Zealand requirements by an appropriately qualified electrical worker.
Frequently Asked Questions About 5 Gang Light Switches
What does 5 gang mean?
It means five separate switches are fitted on one plate for five separately controlled lighting circuits.
Does it support 2-way switching?
The existing product information lists 2-way switching capability. Your electrician should confirm the planned circuit design.
Is it a dimmer?
No. It is a standard on/off switch plate. Use a compatible LED dimmer if dimming is required.
What size is it?
The listed size is W75 × H118 × D30mm.
Is an SDoC available?
Yes. The SDoC is linked above.
Who should install it?
Installation should be completed in accordance with New Zealand electrical requirements by an appropriately qualified electrical worker.
Buy a 5 Gang Light Switch in NZ
Choose this 5 gang vertical light switch when you need five lighting controls on one compact plate. Browse the Green LED switches and power points NZ range for matching products.
